Cane Creek 40-series Zs44 / Ec44 Short Cover Bike Bicycle

Description

Cane Creek 40-Series ZS44/28.6 - EC44/40 Tapered Headset

With the 40-Series ZS44/28.6 - EC44/40 headset from Cane Creek, tapered forks can be installed in frames with a press-fit dimension of 44mm. The upper bearing shell is semi-integrated (ZS), while the lower is external (EC).

Product features - 40-Series ZS44/28.6 - EC44/40

• Model: 40-Series Headset Tapered (ZS44/28.6 - EC44/40)
• Type: Semi Integriert (ZS) / Standard Ahead (EC)
• Steerer: Tapered 1 1/8“- 1 1/2“
• Bearing: Industrial ball bearings
• Installation height: 20mm
• Upper:
  • 1 1/8" Cap - ZS44
  • Mounting height: 8mm
  • Outer diameter: 44mm
  • Inside diameter 28.6mm
• Lower:
  • 1.5" Cap - EC44
  • Mounting height: 12mm
  • Inside diameter: 44mm
  • Outer diameter 40mm
  • Fork cone: 1.5

Without Top Cap
